AGB · Magnetic Lock · Sliding Doors

Wave Sliding

AGB · Made in Italy · Magnetic Sliding

Wave's magnetic technology adapted for the sliding-door pocket. Wave Sliding sits behind the flush pull on a pocket or barn door and gives the leaf a true hook lock that closes silently — the magnet pulls the hook into the strike, then the privacy turn or Euro key engages the deadbolt. WC variant for bathrooms, PZ for office and study sliders. The quiet alternative to Scivola Tre when the door is a slider.

UsePocket · Barn · Sliding doors

ActionMagnetic hook · Privacy or keyed

EntriesWC · PZ

Configure the finish

Anodised silver

Click a swatch to preview the finish on the hero. The default photo is the manufacturer's reference render — ask us for physical samples mailed to your studio.

Choose function

Quantity

In the details

A real lock for a sliding door.

Magnetic hook

The hook deploys with a magnet rather than a manual cam — once the door is closed, the hook pulls itself into the strike silently. The same Wave technology in a sliding form factor.

Privacy & keyed

WC variant uses a privacy turn with emergency release on the corridor side; PZ takes a Euro-cylinder for keyed sliders. Both work with our flush sliding pulls.

Pull integration

Designed for sliding-door flush pulls — Tupai 4181 family, DND ginkgo and luxury sliding sets, and the standard AGB pulls. Recessed faceplate sits within the pull cutout.

Where we specify it

Sliding bathrooms, sliding studies, sliding bedroom suites — anywhere a real lock is needed on a sliding leaf and the spring action of Scivola would register.

Technical specifications

AGB Wave Sliding — full specification

Wave Sliding fits the standard 96 × 18 mm flush-pull cutout used by Tupai, DND, and AGB sliding hardware. The values below are the standard configuration — alternative pull-cutout sizes are available on request.

Closing type	Magnetic hook + Mechanical privacy / keyed
Door Type	Pocket · barn · sliding leaves
Backset (entraxe)	60 mm
Hook stroke	22 mm — full strike engagement
Faceplate cutout	96 × 18 mm (compatible with most flush pulls)
Variants	WC privacy · PZ Euro-cylinder
Cylinder fit	PZ accepts standard Euro 30 / 35 mm
Material	Zinc-die body · steel hook · stainless faceplate
Standards	EN 12209 (sliding)
Anti-corrosion	EN 1670 · Grade 4

Available finishes

4 finishes — specified per project

Finish swatches direct from AGB. Configure the finish in the panel above to update the cart line, or ask us for physical samples mailed to your studio before specification.

Anodised silver

Matt satin chromium plated

Semi-bright black

Matt white RAL 9016

Manufacturer datasheet

Full technical specification on AGB.it

AGB publishes the complete Wave Sliding datasheet — geometry, hook stroke, magnet specs, and pull compatibility — on their website. We mirror the same body and finish options through our specification.

External · Manufacturer

Wave Sliding — AGB product page

agb.it · Opens in new tab

Specify this lock

Specify Wave Sliding on your pocket doors.

Tell us the leaf size, the pull family, and whether the slider needs privacy (WC) or a key (PZ). We'll prep the leaf and supply the lock and strike together.

Inquire about Wave Sliding
